body type 4/5 seater hatchback
number of doors 3
designer
dimensions & weights
mm inches
wheelbase 2540 100
track/tread (front) 1471 57.9
track/tread (rear) 1430 56.3
length 4030 158.7
width 1750 68.9
height 1420 55.9
ground clearance
length:wheelbase ratio 1.59
kerb weight 1190 kg 2624 lb
weight distribution
fuel tank capacity 60 litres 13.2 UK Gal 15.9 US Gal
aerodynamics
drag coefficient
frontal area
cda
engine
engine type naturally aspirated petrol
engine manufacturer Fiat
engine code
cylinders Straight 5
capacity 2 litre
1998 cc
(121.925 cu in)
bore × stroke 82 × 75.65 mm
3.23 × 2.98 in
bore/stroke ratio 1.08
double overhead camshaft (DOHC)
4 valves per cylinder
20 valves in total
maximum power output
(ec) 154 PS (152 bhp) (113 kW)
at 6500 rpm
specific output
(ec) 76.1 bhp/litre
1.25 bhp/cu in
maximum torque
(ec) 186 Nm (137 ft·lb) (19 kgm)
at 3750 rpm
specific torque
(ec) 93.09 Nm/litre
1.13 ft·lb/cu3
engine construction
sump
compression ratio 10.7:1
fuel system SMPFi
bmep (brake mean effective pressure) 1169.8 kPa (169.7 psi)
maximum rpm
crankshaft bearings
engine coolant Water
unitary capacity 399.6 cc
aspiration Normal
compressor N/A
intercooler None
catalytic converter Y
performance
acceleration 0-80km/h (50mph)
acceleration 0-60mph
acceleration 0-100km/h 8 s
acceleration 0-160km/h (100mph)
standing quarter-mile
standing kilometre 29 s
maximum speed 213 km/h (132 mph)
power-to-weight ratio 129.51 PS/g
95.25 kW/g
127.73 bhp/ton
0.06 bhp/lb
weight-to-power ratio 10.5 kg/kW
17.54 lb/bhp
fuel consumption
fuel consumption 13.1/7.2/9.4 l/100km urban/extra-urban/combined
universal consumption (calculated from the above)
litres per 100km 13.1/7.2/9.4 l/100km urban/extra-urban/combined
km per litre 7.6/13.9/10.6 km/l urban/extra-urban/combined
uk mpg 21.6/39.2/30.1 UK MPG urban/extra-urban/combined
us mpg 18.0/32.7/25.0 US MPG urban/extra-urban/combined
carbon dioxide emissions
carfolio calculated co2 ? 218.08 g/km
ved band (uk)
co2 effizienz (de)
chassis
engine position front
engine layout transverse
drive wheels front wheel drive
torque split N/A
steering rack & pinion PAS
turns lock-to-lock
turning circle 10.80 m
front suspension I.MS.LW.ARB.
rear suspension I.ARB.
wheel size front
wheel size rear
tyres front 195/55 R 15 84V
tyres rear 195/55 R 14 84V
brakes f/r VeDi/Di-S
front brake diameter 284 mm
rear brake diameter 240 mm
gearbox 5 speed manual
top gear ratio 0.97
final drive ratio 3.56
http://www.carfolio.com/specifications/models/car/?car=75570
There was also Abarth style package
