Ferrari Formula Zagato 93 (FZ93) FS1 1994

[Neddo]

Engine
Configuration 180º flat 12
Location Mid, longitudinally mounted
Construction aluminium alloy block, aluminium head
Displacement 4,943 cc / 301.6 cu in
Bore / Stroke 82.0 mm (3.2 in) / 78.0 mm (3.1 in)
Compression 9.2:1
Valvetrain 4 valves / cylinder, DOHC
Fuel feed Bosch K-Jetronic Fuel Injection
Aspiration Naturally Aspirated
Power 390 bhp / 291 KW @ 6,300 rpm
Torque 490 Nm / 361 ft lbs @ 4,500 rpm
BHP/Liter 79 bhp / liter

Drivetrain
Chassis aluminium body on steel tubular chassis
Front suspension double wishbones, coil springs, co-axial Koni dampers
Rear suspension double wishbones, double coil springs, twin co-axial Koni dampers
Steering rack-and-pinion
Brakes ventilated discs, all-round
Gearbox 5 speed Manual
Drive Rear wheel drive
http://www.ultimatecarpage.com/car/4682/Ferrari-FZ93.html
http://www.supercars.net/cars/3436.html



[Mike_grpA]

Cool car, but just one thing. It's not a V12, it's a boxer. 180 degrees is horizontally opposed. Sorry for nit picking, but I love the Ferrari flat 12s lol.



[JKgo]

...Front's okay but that back... nope. ಠ_ಠ



[ClydeYellow]

Cool car, but just one thing. It's not a V12, it's a boxer. 180 degrees is horizontally opposed. Sorry for nit picking, but I love the Ferrari flat 12s lol.

Technically speaking, it's not a boxer either.



[Neddo]

I'm actually surprised that this car is getting positive reception because many consider it one of ugliest Ferraris



[Mike_grpA]

Technically speaking, it's not a boxer either.

You're right, I hadn't realised Ferrari built their flat engines that way, always assumed they were boxers, mostly due to Ferrari themselves calling them boxers (the bb in 365bb and 512bb stands for berlinetta boxer). A flat 12 then. As far as the car being ugly, I think it is ugly, but it's interesting too.



[HKS racer]

I don't like it. I would prefer a 599XX or even better a FXXK.



[Neddo]

I don't like it. I would prefer a 599XX or even better a FXXK.

Actually equivallent of this car would be F12 and it's one offs and versions like TRS



[ClydeYellow]

I'm actually surprised that this car is getting positive reception because many consider it one of ugliest Ferraris

True that, but it's still a flat-12 Ferrari. It could look like having Ebola and I'd still love it.



[Neddo]

And it's got popup lights @ClydeYellow
